Multi-cores Breakout Armored Cable (GJSFJV)

LSZH or PVC jacket.
It is the construction stainless steel tube with Dupont aramid yarn provide the cable enough tensile strength and pressure strength.
Add stainless steel weave mesh can further enhance cable tension, and enhance the performance of rat bite prevention.
Circular section design. convenient line grooves. pipes Small volume.good bending radius,easy to stripping, convenient for operation

Description
Inquiry

Characteristics:
LSZH or PVC jacket.
It is the construction stainless steel tube with Dupont aramid yarn provide the cable enough tensile strength and pressure strength.
Add stainless steel weave mesh can further enhance cable tension, and enhance the performance of rat bite prevention.
Circular section design. convenient line grooves. pipes Small volume.good bending radius,easy to stripping, convenient for operation.

Applications:
Room indoor wiring.
FTTH optical home, user terminal.
Shaft, building wiring.

Ordering Information:
Fiber type in details
For example: GJSFJV 48core SM/G657A2

Standard:
ICEA-596, GR-409, YD/ T2488-2013

Specifications:

fiber count	(mm} Inner cable diameter	Inner	（mm）outer diameter	（g/M）weight	max（N）tension		（N）max crush resistance		（MM）bending radius
fiber count	(mm} Inner cable diameter	Inner	（mm）outer diameter	（g/M）weight	short time	long time	short time	long time	static	Dynamic
2-4	Φ2.0mm single fiber	2-4	Φ7.0mm	42	500	1200	500	2000	10D	20D
4-12	Φ3.0mm inimulti-core	1	Φ5.0mm	58	350	800	500	2000	10D	20D
12-24	Φ3.0mm inimulti-core	4	Φ9.5mm	68	500	1200	500	2000	10D	20D
24-48	Φ3.0mm Minimulti-core	4	Φ9.5mm	75	500	1200	500	2000	10D	20D
